Operating With the Operation Panel -1 (Factory Setting State)
䊶Frequency setting: Digital setting (Parameter P09=0)
䊶Forward /reverse run function: Start/stop, rotation direction mode setting (Parameter P08=0)
Power ON
Frequency
setting
Press the MODE button.
0 5. 0
r
䂥
Run command
Press the SET button.
(The main display will flicker.)
The main display lamp will turn ON.
000
[Example for rotating in forward direction at operating frequency 5Hz]
Stop command
Press the STOP button. The motor will
start to decelerate and will stop.
STOP
0 00
MODE
SET
F
0 0. 5
䂯
Press theƷ(up) or(down) buttons
to display 5Hz on the main display.
(The main display will flicker.)
Press the SET button to set the data.
SET
0 00
Press the RUN button.
As the factory setting is the forward
operation, the motor will start rotating in
the forward direction and operate at 5Hz.
RUN
0 5. 0
[Example for rotating in forward direction at operating frequency 10Hz]
Changing the
frequency
during
operation
Press the MODE button.
1 0. 0
r
䂥
Press the SET button.
(The main display will flicker.)
MODE
SET
F
0 5. 0
䂯
Press theƷ(up) or(down) buttons
to display 10Hz on the main display.
(The main display will flicker.)
Press the SET button to set the data.
The display will change to the output
frequency, and will reach 10Hz.
SET
1 0. 0
[Stopping operation]
[Changing the frequency with theƷandbuttons during operation (MOP function)]
The operating frequency can be changed with theƷandbuttons during operation.
䊶 If theƷ(up) button is held down, the operating frequency will increase.
䊶 If the(down) button is held down, the operating frequency will decrease.
Note ) Once the operating frequency is determined, press the MODE button and then
press the SET button twice to set the operating frequency.
If this is not carried out, this frequency will not be saved when the power is
turned OFF.
Main display
26
