䃂 Operation mode of door control
䊶 The operation mode of door control may be independently set as OPEN operation
mode and CLOSE operation mode.
䊶 According to the position of the door detected by encoder signal, speed change
SW signal and Arrival signal, the operation is carried out by frequency of Parameter
d14 to d27 and the acceleration/deceleration time of d28 to d39.
䃂 Acceleration/deceleration time
䊶 Data setting value=[0],[3],[6]:
Operation is set according to P01 and P02(1st acceleration time and 1st deceleration time).
䊶 Data setting value=[1],[2],[4],[5]:
Depending on operation mode of door control.
Note) If input CLOSE signal to OPEN operation or input OPEN signal to CLOSE operation,
the operation is carried out by 1st acceleration time and 1st deceleration time of P01 and P02.
䃂 Door control encoder method
䊶 Door control encoder method is operated after the door width setting value of
Parameter d01 is set correctly.
Data
setting
value
Control method
Operation panel
㪇
Frequency setting value
䋱
Digital setting(by setting value of Fr mode)
Digital setting(by setting value of Fr mode)Communication RS485
Door control(normal)
encoder method
Operation mode of door control
(Parameter d14 to d27)
䋲
Door control(repeat)
encoder method
Operation mode of door control
(Parameter d14 to d27)
䋳
Door control
(door amplitude detect)
encoder method
Detecting frequency of door width
(Parameter d52)
䋴
Door control (normal)
SW method
Operation mode of door control
(Parameter d14 to d27)
䋶
䋵
Door control (repeat)
SW method
Operation mode of door control
(Parameter d14 to d27)
FREQUENCY SETTING SIGNAL(Parameter P09)
There are three options for frequency setting signal: by operation panel (near),
by operation mode controlled by door or by command from communication.
In case of door control, encoder mode and SW mode may be selected.
When the door control is being repeated and the door amplitude is being
detected, the operation direction of the door may change automatically.
Secure personal safety before operation.
Failure to do so could lead to injury.
45
Caution
!
