Operating With the Operation Panel -2
䊶Frequency setting: Digital setting (Parameter P09=0)
䊶Forward / reverse run function: Forward run/reverse run operation (Parameter P08=1)
r
[Example to change from forward run to reverse run during operation]
[Stopping operation]
Press the STOP button.
The motor will start to decelerate
and will stop.
STOP
0 00
Reverse run
setting
Press the䂯(down) button, and set
the rotation direction to reverse run.
䋭F
䂯
Run command
Stop command
Press the RUN button.
The motor will gradually decelerate,
and will start forward rotation at
5Hz again.
RUN
5. 0
0. 0
5. 0
Forward
Reverse
[Canceling the rotation direction setting]
After setting with the䂥and䂯buttons, the rotation direction can be canceled by pressing
the same button again.
Note) If the RUN button is pressed after setting the rotation direction, the rotation
direction will not changed.
Power ON
Forward run
setting
Press the䂥(up) button, and set the
rotation direction to forward run.
(Press the䂯button to set reverse run.)
䋭
F0
䂥
Run command
Press the RUN button.
The motor will start rotating in the
forward direction and operate at 5Hz.
RUN
5. 0
The main display lamp will turn ON.
000
[Example for rotating in forward direction at operating frequency 5Hz]
䊶Set rotation direction (F: Forward run, r: Reverse run)
䊶Current state (0: Stop, F: Forward run, r: Reverse run)
䊶Set rotation direction (r: Reverse run)
䊶Current state (F: Forward run)
Frequency
setting
Press the MODE button.
0 5. 0
r
䂥
Press the SET button.
(The main display will flicker.)
MODE
SET
F
0 0. 5
䂯
Press the 䂥(up) and䂯(down) buttons
to display 5Hz on the main display.
(The main display will flicker.)
Press the SET button to set the data.
SET
0 00
Main display
28
To Next Page
