䃂 Control terminal status (Input signal/output signal) (n16 and n17)
䊶 The statuses of the input and output signals of the control circuit terminal
can be monitored by "Lightening/Lightening out of each LED segment".
䃂 Encoder detection status (n11)
䊶 Indicates the pulse frequency of the encoder signal.
䊶 Also indicates the rotation direction of the motor by the encoder signal.
F: Forward run (OPEN operation), r: Reverse run (CLOSE operation)
Note) In the non-encoder mode (Parameter P09 = [1, 2, 3]), the encoder detection status
(n11) cannot be detected. The panel display will be "0.0".
32
䃂 Door position area (n07)
䊶 Indicates the operation area of the door position.
[0]: CLOSE hold operation area, [1 to 6]: OPEN operation area
[7]: OPEN hold operation area, [8 to 13]: CLOSE operation area
䃂 Door position (n08)
䊶 Indicates the data value of the door position. (Data range: 1 to 65535)
䃂 OPEN arrival position data (n09)
䊶 Indicates the data value of the door position while the OPEN arrival signal is
changing from OFF to ON.
Operation panel display: Displays as 1 ˙[0.01] and 10,000 ˙[100.].
Monitor by communication function: Directly displays the door position data.
Operation panel display: Displays as 1 ˙"0.01" and 10,000 ˙"100.".
Monitor by communication function: Directly displays the door position data.
䃂 No. of door switching (n10)
䊶 Number of switching can be monitored up to 65,535 times.
Operation panel display: Displays as 1 time ˙"0.01" and 10,000 times ˙[100.].
Monitor by communication function: Directly displays the number of switching.
䊶 The data of the number of switching can be cleared by setting the parameter
P42 (setting data clear) to "2".
