Troubleshooting guide/Specifi cations
Specifi cations
Recording system DVD-RAM : DVD Video Recording format
DVD-R : DVD-Video format
DVD-R DL (Dual Layer) : DVD-Video format
DVD-RW : DVD-Video format
+R
+R DL (Double Layer)
+RW
Recordable discs
DVD-RAM: 2X SPEED (Ver. 2.0),
2-3X SPEED (Ver. 2.1), 2-5X SPEED (Ver. 2.2)
DVD-R: 1X SPEED (Ver. 2.0), 1-4X SPEED (Ver. 2.0),
1-8X SPEED (Ver. 2.0), 1-16X SPEED (Ver. 2.1)
DVD-R DL: 2-4X SPEED (Ver. 3.0), 2-8X SPEED (Ver. 3.0)
DVD-RW: 1X SPEED (Ver. 1.1), 1-2X SPEED (Ver. 1.1),
2-4X SPEED (Ver. 1.2), 2-6X SPEED (Ver. 1.2)
+R: 2.4X SPEED (Ver. 1.0), 2.4-4X SPEED (Ver. 1.1),
2.4-8X SPEED (Ver. 1.2), 2.4-16X SPEED (Ver. 1.3)
+R DL: 2.4X SPEED (Ver. 1.0), 2.4-8X SPEED (Ver. 1.1)
+RW: 2.4X SPEED (Ver. 1.1), 2.4-4X SPEED (Ver. 1.2)
Recording time Maximum 8 hours (using 4.7 GB disc)
XP: Approx. 1 hour, SP: Approx. 2 hours
LP: Approx. 4 hours, EP: Approx. 6 hours/8 hours
Maximum Approx. 441 hours with 250 GB HDD (EP 8 hours mode)
XP: Approx. 55 hours, SP: Approx. 110 hours
LP: Approx. 221 hours, EP: Approx. 331 hours/441 hours
Playable discs
DVD-RAM : DVD Video Recording format
DVD-R : DVD-Video format, MP3*
1
, JPEG*
1
, DivX*
1
DVD-R DL (Dual Layer) : DVD-Video format, MP3*
1
, JPEG*
1
, DivX*
1
DVD-RW : DVD-Video format, DVD Video Recording format
+R, +R DL (Double Layer), +RW
DVD-Video, CD-Audio (CD-DA), Video CD, SVCD*
2
CD-R/CD-RW : CD-DA*
1
, Video CD*
1
, SVCD*
1
*
2
, MP3*
1
, JPEG*
1
,
DivX*
1
Internal HDD capacity 250 GB
Optical pick-up System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER specifi cation
Class 1 LASER Product (Pickup)
Wave length:
CD 780 nm wave length
DVD 662 nm wave length
Laser power:
No hazardous radiation is emitted with the safety protection
Audio
Recording system: Dolby Digital 2ch, Linear PCM (XP mode)
Audio in: AV1/AV2 (21 pin), AV3 (pin jack)
Input level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Input impedance: More than 10 kΩ
Audio out: AV1/AV2 (21 pin), Audio Out (pin jack)
Output level: Standard: 0.5 Vrms, Full scale: 2.0 Vrms at 1 kHz
Output impedance: Less than 1 kΩ
Digital audio out: Optical terminal (PCM, Dolby Digital, DTS, MPEG)
HDMI Output 19 pin type A: 1 pc
HDMI
TM
(V.1.3 with Deep Colour)
y This unit supports “HDAVI Control 3” function.
Video
Video system:
SECAM (only input)/PAL colour signal, 625 lines, 50 fi elds
NTSC colour signal, 525 lines, 60 fi elds
Recording system: MPEG2 (Hybrid VBR)
Video in (PAL/SECAM/NTSC):
AV1/AV2 (21 pin), AV3 (pin jack) 1 Vp-p 75 Ω, termination
S-Video in (PAL/SECAM/NTSC):
AV2 (21 pin), AV3 (S terminal) 1 Vp-p 75 Ω, termination
RGB in (PAL): AV2 (21 pin) 0.7 Vp-p (PAL) 75 Ω, termination
Video out (PAL/NTSC):
AV1/AV2 (21 pin), Video Out (pin jack) 1 Vp-p 75 Ω, termination
S-Video out (PAL/NTSC):
AV1 (21 pin), S-Video Out (S terminal) 1 Vp-p 75 Ω, termination
RGB out (PAL/NTSC):
AV1 (21 pin) 0.7 Vp-p (PAL) 75 Ω, termination
Component video output (NTSC 480p/480i, PAL 576p/576i)
Y: 1.0 Vp-p 75 Ω, termination
P
B
: 0.7 Vp-p 75 Ω, termination
P
R
: 0.7 Vp-p 75 Ω, termination
VHS
Recording format:
VHS Video Cassette System Standard with FM audio
Heads: 4 Helical Scan Heads for Video
2 Helical Scan Heads for FM audio
1 Fixed Head for Normal audio
Tape speed/Recording time (with E-240 tape):
PAL: SP: 23.39 mm/s, 240 min
LP: 11.7 mm/s, 480 min
EP: 7.8 mm/s, 720 min
NTSC: SP: 33.35 mm/s, 168 min
EP: 11.12 mm/s, 505 min
Television system
Tuner system Channel coverage
PAL-BGH
SECAM-BG
(CCIR)
VHF: E2–E12, A–H2 (Italy)
UHF: 21–69
CATV: S01–S05 (S1–S3),
S1–S20 (M1–U10), S21–S41
SECAM-LL’
(France)
VHF: 2–10
UHF: 21–69
CATV: B–Q (100.5 to 299.5 MHz),
S21–S41 (299.25 to 467.25 MHz)
DVB-T
(Germany)
VHF: 5–12
UHF: 21–69
DVB-T
(France)
VHF: 5–10
UHF: 21–69
DVB-T
(Italy)
VHF: D–H2
UHF: 21–69
DVB-T
(Spain/
Switzerland)
VHF: 5–12
UHF: 21–69
RF converter output: Not provided
SD Card
Slot: SD Memory Card slot: 1 pc
Compatible media: SD Memory Card*
3
, SDHC Memory Card,
MultiMediaCard
Format: FAT12, FAT16*
4
(In case of SD Memory Card/MultiMediaCard)
FAT32*
4
(In case of SDHC Memory Card)
Still picture (JPEG)
Image fi le format:
JPEG conforming DCF (Design rule for Camera File system),
Number of pixels: Between 34 × 34 and 6144 × 4096
sub sampling; 4:2:2 or 4:2:0
Thawing time: Approx. 1.9 sec (6 M pixels, JPEG)
Video (SD Video)*
5
Codec: MPEG 2 (SD-Video Entertainment Video Profi le)
File Format: SD-Video format conforming
DV input IEEE 1394 Standard, 4 pin : 1 pc
USB port Type A : 1 pc
USB standard: USB 2.0 High Speed
Format: FAT16, FAT32
Video (SD Video)*
5
Codec: MPEG 2 (SD-Video Entertainment Video Profi le)
File Format: SD-Video format conforming
Others
Region code: # 2
Operating temperature: 5 °C to 40 °C
Operating humidity range: 10 % to 80 % RH (no condensation)
Power supply: AC 220 to 240 V, 50 Hz
Power consumption: Approx. 40 W
Dimensions (W×H×D): 430 mm × 84 mm × 341 mm
(excluding the projecting parts)
430 mm × 84 mm × 350 mm
(including the projecting parts)
Mass: Approx. 6.3 kg
Power consumption in standby mode:
Approx. 2 W (Power Save mode)
Approx. 22 W (Quick Start mode)
Note
Specifi cations are subject to change without notice.
*
