Panasonic KX-TDA100D

Dialled Number
Corresponding Routing
Plan Table No.
Description
039-654-321 1 "039" is found in location 0001 and the Inter-digit
time expired before the seventh digit is received.
The Routing Plan Table 1 is selected after the
Inter-digit time expired.
® 4.4 [2-3] Timers & Counters—Dial / IRNA /
Recall / Tone—
Dial—Extension Inter-digit
038 4 "03" is found in two locations (locations 0001 and
0002), so the PBX waits for the next digit "8".
"038" is not found in any location, then
"03" (location 0002) is selected. The Routing Plan
Table 4 is selected.
4. Routing Plan Table
4
Assignment
Arrange the time schedule as desired and store the carrier priority.
Time Table
5
As the best carrier may vary with the day of the week and the time of day, four time blocks (Time-A through
D) can be programmed for each day of the week.
® 10.4 [8-3] Routing Plan Time—Time Setting
® [330] ARS Routing Plan Time Table
Carrier Priority
6
Assign the appropriate carrier (refer to "5. Carrier Table
7
Assignment") and their priority in each time
block. The carrier is selected in the entry order (the order in which entries are listed).
® 10.5 [8-4] Routing Plan Priority
® [331–346] ARS Routing Plan Table (1–16)
ARS Routing Plan Table
9:00
12:00
15:00
21:00
:
9:00
12:00
15:00
21:00
1 (A telecom)
1 (A telecom)
1
(A telecom)
3 (C telecom)
:
3
(C telecom)
3 (C telecom)
3 (C telecom)
3 (C telecom)
Time-A
Time-B
Time-C
Time-D
:
Time-A
Time-B
Time-C
Time-D
SUN
:
SAT
Time Table
Routing Plan Table
1
Carrier
Priority 1 Priority 2
...
5
6
4 (D telecom)
2 (B telecom)
2
(B telecom)
1 (A telecom)
:
2
(B telecom)
1 (A telecom)
1 (A telecom)
2 (B telecom)
...
...
...
...
...
...
...
...
...
ARS Leading Number Table
0001
:
Location
No.
Routing Plan
Table No.
1
:
Leading
No.
03
:
Additional
(Remain)
No. of Digits
8
:
3
4
5. Carrier Table
7
Assignment
A specified number of carriers can be programmed. Assign the following items for each Carrier Table:
® 10.6 [8-5] Carrier—Carrier
Carrier Name
8
: Assign the carrier name.
® 10.6 [8-5] Carrier—Carrier—
Carrier Name
® [350] ARS Carrier Name
144 Feature Guide
1.10.1 Automatic Route Selection (ARS)
