Panasonic KX-TDA100D

Pattern B: 80 digits with call charge information
(1)
(2) (3) (4) (5)
(7) (8) (9)(10)
Cost
(8+2)
00560.00EU
Duration
(8)
00:00'05
Time
(7)
10:03AM
10:07AM
Date
(8 digits)
01/02/02
01/02/02
Dial Number
(20)
<I>
1234567890123456789
ACC Code
(10)
9876543210
CD
(3)
NA
CO
(2)
01
01
Ext
(5)
1210
2005
Pattern C: 120 digits
(1)
(2) (3) (4) (5)
(6) (7) (8) (9)(10)
Cost
(8+3)
00560.00EUR
Duration
(8)
00:00'05
00:00'05
Time
(7)
10:03AM
10:07AM
Date
(8 digits)
01/02/02
01/02/02
Dial Number
(50)
123456789012345678901234567890
<I>ABC COMPANY123456789012345
ACC Code
(10)
9876543210
9876543210
CD
(3)
TR
TR
CO
(4)
0001
0001
Ext
(5)
1230
1230
Ring
(4)
0'05
[Explanation]
The following table explains the SMDR contents which are based on the numbers in the previous pattern
examples. For the programmable items, refer to the following [Programmable Items].
Number in
the Pattern
Item Description
(1) Date Shows the date of the call.
(2) Time Shows the end time of a call as Hour/Minute/AM or PM.
(3) Ext
(Extension)
Shows the extension number, floating extension number, etc.,
which was engaged in the call.
Also shows the following codes:
Dxxx: Outgoing trunk call from a doorphone (xxx=doorphone
number) (® 1.17.1 Doorphone Call)
Txxx: Outgoing trunk call by TIE line service (xxx=trunk group
number)
*xxx: Verified call (xxx=verification code) (® 1.9.6 Verification
Code Entry)
(4) CO (Trunk) Shows the trunk number used for the call.
For patterns A and B, "00" will be shown for trunk numbers over
hundred.
Feature Guide 285
1.26.1 Station Message Detail Recording (SMDR)
