Panasonic KX-TDA100D

Number in
the Pattern
Item Description
(9) CD (Condition
Code)
Shows other call information with the following codes:
CL: Collect call
TR: Transfer
FW: FWD to trunk
D0: Call using DISA or TIE line service
RM: Remote maintenance (modem) (® 2.3.1 PC Programming)
NA: Not answered call
RC: Received call
AN: Answered call
VR: Received call with Call Waiting Caller ID (Visual Caller ID)
VA: Answered call with Call Waiting Caller ID (Visual Caller ID)
(10) Cost Shows the call charge.
[Programmable Items]
Item
Description
Outgoing trunk call Controls whether the outgoing trunk calls are shown. This setting
is common throughout the PBX. COS programming is also
required.
® 13.1 [11-1] Main—SMDR—
Print Information—Outgoing
Call
® [804] SMDR Outgoing Call Printing
Incoming trunk call Controls whether the incoming trunk calls are shown.
® 13.1 [11-1] Main—SMDR—
Print Information—Incoming
Call
® [805] SMDR Incoming Call Printing
Outgoing intercom call Controls whether the outgoing intercom calls are recorded.
® 13.1 [11-1] Main—SMDR—
Print Information—Intercom
Call
Log-in/Log-out status Controls whether the log-in/log-out status is recorded.
® 13.1 [11-1] Main—SMDR—
Print Information—Log-in /
Log-out
ARS dial Controls whether the user-dialled number or the modified number
is shown.
The Host PBX Access code ("=" followed by the access code) can
be shown (as supplementary information) only when the modified
number is selected in this setting. (® 1.10.1 Automatic Route
Selection (ARS))
® 13.1 [11-1] Main—SMDR Options—
SMDR Options—ARS
Dial
Caller’s identification Controls whether the caller’s identification number, name,
number and name, or nothing is shown. If "none" is selected, <I>
will not be shown.
® 13.1 [11-1] Main—SMDR Options— SMDR Options—Caller
ID Number & Name
Feature Guide 287
1.26.1 Station Message Detail Recording (SMDR)
