14
SQW0038
Before Use
Names and Functions of Main Parts
1 Self-timer indicator (→148) /
AF Assist Lamp (→53, 125)
2 Control ring (→39)
3 Aspect ratio selector switch
(→107)
4 Hot shoe (Hot shoe cover) (→176)
The hot shoe cover is already
attached to the hot shoe at the time
of purchase.
5 Aperture ring (→59)
6 Focus selector switch
(→114, 126, 128)
7 Lens front ring
To attach the auto lens cap
(optional)
*
, remove the lens front
ring.
*
Some optional accessories
may not be available in some
countries.
8 Lens barrel
9 Lens (Filter diameter Φ43 mm)
1 2 5 643
9 8 7
To Next Page
