158
SQW0038
Functions for specific subjects and purposes
Creating stop motion animation [Stop Motion Animation]
9
Press to select [OK] and press
[MENU/SET]
A confirmation screen is displayed. If you select [Yes],
the operation is executed.
You can also create a stop motion animation using
[Stop Motion Video] in the [Playback] menu. (→215)
Adding pictures to an already recorded stop motion animation group
When you select [Additional] in step
4
, group pictures recorded using [Stop Motion
Animation] are displayed. Select a group picture and press [MENU/SET]. Then, select
[Yes] on the confirmation screen.
[Auto Shooting] may not be performed according to the preset interval because recording could
take time under some recording conditions, such as when pictures are taken using a flash.
When you select the picture quality for an aspect ratio that is different from the original picture, the
picture will be displayed with a black band on the upper/lower side or the left/right side of a stop
motion animation.
When you select the picture quality for an aspect ratio that is different from the original picture, this
will produce grainy pictures in a stop motion animation.
Use a sufficiently charged battery or an AC adaptor (optional) and DC coupler (optional).
If the power supply is cut off due to a power outage or AC adaptor disconnection while a motion
picture is being recorded using the AC adaptor (optional), that motion picture will not be recorded.
You cannot create a motion picture that is longer than 29 minutes 59 seconds, or whose file
exceeds 4 GB.
When a stop motion animation is shorter than 2 seconds, “2s” will be displayed for the motion
picture recording time (→70).
If only one still picture is recorded, it will not be recorded as a group picture. You cannot select
only one recorded still picture using [Additional].
Not available in the following cases:
[Stop Motion Animation] cannot be used in the following cases:
During panorama picture recording
When [Multi Exp.] is set
When using [Time Lapse Shot]
When the [Simultaneous record w/o filter] is set to [ON]
