250
SQW0038
Wi-Fi
Sending pictures to a PC
[Send Images Stored in the Camera]
1
Set the menu
→ [New Connection] → [Send Images Stored in the Camera] → [PC]
2
Select [Via Network] or [Direct] to connect (→263)
3
Select the PC you want to connect to
If the PC you want to connect to is not displayed, select [Manual Input], then enter the computer
name (for Mac, enter the NetBIOS name).
4
Select the folder you want to send to
When the connection is established, the confirmation screen for the transmission setting is
displayed. Check the setting and press [MENU/SET]. To change the send setting, press [DISP.]
button. (→271)
5
Select [Single Select] or [Multi Select]
[Single Select]
Select the picture
Press [MENU/SET]
[Multi Select]
Select the picture (repeat)
If selected again, the setting will be cancelled.
Select [OK]
The number of pictures that can be sent by [Multi Select] is
limited.
2 3
4 5 6
1
OK
A confirmation screen is displayed. If you select [Yes], the operation is executed.
To change the send setting, press [DISP.] button.
To close the connection, select [Exit].
Folders sorted by the sent date are created in the specified folder, and pictures are saved in those
folders.
If the screen for a user account and password entry appears, enter the one you set on your PC.
If the computer name (for Mac, the NetBIOS name) contains spaces, etc., the name may not be
properly recognised. If you cannot connect, we recommend changing the computer name (for
Mac, the NetBIOS name) to a combination of 15 or less alphanumeric characters only.

Table of Contents

Other manuals for Panasonic Lumix DMC-LX100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-LX100 and is the answer not in the manual?

Panasonic Lumix DMC-LX100 Specifications

General IconGeneral
Megapixel12.8 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size4/3 \
Image formats supportedJPG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4112 x 3088 pixels
Still image resolution(s)[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom4 x
Optical zoom3.1 x
Focal length range10.9 - 34 mm
Maximum aperture number16
Minimum aperture number1.7
Lens structure (elements/groups)11/8
Maximum focal length (35mm film equiv)75 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)51200
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)0.3 - 8.5 m
Flash range (wide)0.6 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)921000 pixels
Magnification1.39 x
Viewfinder screen size0.38 \
USB version-
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editingCrop, Resizing, Rotating
Photo effectsArt, Black&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Image processorVenus
Self-timer delay2, 10 s
Camera file systemDCF, DPOF, Exif 2.3, RAW
Image quality adjustmentColour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Power source typeBattery
Battery voltage7.2 V
Battery capacity1025 mAh
Battery life (CIPA standard)350 shots
Product colorSilver
Cables includedAC, USB
Bundled softwarePHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth55 mm
Width114.8 mm
Height66.2 mm
Weight351 g
Weight (including battery)393 g
