Panasonic Lumix DMC-LX100 Operating Instructions

306
SQW0038
Others
Menu list
[Custom]
You can set operations of this unit, such as the screen display method and functions of a
button, according to your preferences. You can also register the changed settings.
[Utilize Custom Set
feature]
Calls up the setting registered using [Cust.Set Mem.]. →60
[Cust.Set Mem.] Registers the current camera settings as a custom setting. →60
[Silent Mode] Disabling the beeps and flash at the same time. →161
[AF/AE Lock]
Performs the lock setting of the focus and/or exposure used for
executing AF/AE lock.
→133
[AF/AE Lock Hold]
Sets the [AF/AE LOCK] button operation used for recording by
fixing the focus and/or exposure.
→133
[Shutter AF]
Enables focus adjustment automatically when the shutter button is
pressed halfway.
→124
[Half Press Release]
Enables shutter release when the shutter button is pressed
halfway.
→124
[Quick AF] Enables faster focusing when the shutter button is pressed. →124
[Eye Sensor AF] Automatically adjusts the focus when the eye sensor is activated. →55
[Pinpoint AF Time]
Sets the time for displaying the enlarged screen if the shutter
button is pressed halfway when Auto Focus mode is set to [
].
→122
[Pinpoint AF Display]
Sets whether the assist screen is to be enlarged on a part of the
screen or the entire screen when Auto Focus mode is set to [
].
→122
[AF Assist Lamp]
Illuminates the AF Assist Lamp when the shutter button is pressed
halfway when it is too dark to facilitate focusing.
→125
[Direct Focus Area]
Moves the AF area or MF assist using the cursor button while
recording.
→123
→131
[Focus/Release
Priority]
Disables recording when a subject is out of focus. →125
[AF+MF] Allows manual adjustment of the focus after AF is performed. →125
[MF Assist] Sets the display method for MF Assist (enlarged screen). →131
[MF Assist Display]
Sets whether the Assist screen (enlarged screen) is to be enlarged
on part of the screen or over the entire screen.
→132
[MF Guide]
Displays the MF guide used to check the direction of focus on the
screen when the focus is manually adjusted.
→129

Panasonic Lumix DMC-LX100 Specifications

General

Megapixel	12.8 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4112 x 3088 pixels
Still image resolution(s)	[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom	4 x
Optical zoom	3.1 x
Focal length range	10.9 - 34 mm
Maximum aperture number	16
Minimum aperture number	1.7
Lens structure (elements/groups)	11/8
Maximum focal length (35mm film equiv)	75 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 8.5 m
Flash range (wide)	0.6 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	921000 pixels
Magnification	1.39 x
Viewfinder screen size	0.38 \
USB version	-
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Image processor	Venus
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF, Exif 2.3, RAW
Image quality adjustment	Colour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	350 shots
Product color	Silver
Cables included	AC, USB
Bundled software	PHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader

Weight and Dimensions

Depth	55 mm
Width	114.8 mm
Height	66.2 mm
Weight	351 g
Weight (including battery)	393 g
