Panasonic RR-US310 - Specifications

VQT4R68
42
42
Specifications
Power
Dry-cell battery DC 1.5 V (1 AAA LR03 battery
(alkaline battery))
Audio
Recording/Playback
bit rate
(XP, LP, SLP: sound
quality)
([ ] : recording with external
microphone jack)
XP : MP3 192 kbps
Monaural [Stereo]
LP : MP3 96 kbps
Monaural [Stereo]
SLP : MP3 32 kbps
Monaural [Monaural]
Sampling frequency
(The bracket [ ] shows the
sound quality.)
44.1 kHz [XP : MP3 192 kbps]
44.1 kHz [LP : MP3 96 kbps]
16 kHz [SLP : MP3 32 kbps]
Recording format MP3
Playable bit rate
(“MUSIC” folder)
16 kbps to 320 kbps (MP3)
Playable sampling
frequency
(“MUSIC” folder)
8 kHz to 48 kHz (MP3)
Frequency
characteristic
(-10 dB, recording/
playback, external
microphone jack)
(The bracket [ ] shows the
sound quality.)
60 Hz to 19,000 Hz
[XP : MP3 192 kbps]
60 Hz to 15,000 Hz
[LP : MP3 96 kbps]
60 Hz to 5,400 Hz
[SLP : MP3 32 kbps]
Built-in microphone S/N
(The bracket [ ] shows the
sound quality.)
45 dB [XP : MP3 192 kbps]
Filter (JIS A)
USB USB2.0 (Hi-Speed)
DC 5 V / 150 mA
Audio
output
Earphone ø 3.5 mm, 16 Ω,
Max. 3.6 mW + 3.6 mW
Speaker
output
ø 20 mm, 8 Ω,
Max. 80 mW
Audio
input
External
microphone
jack
ø 3.5 mm Stereo
2.2 mV
plug in power
Max. dimensions
(W × H × D)
37.5 mm (W) × 107.8 mm (H) ×
15.7 mm (D)
Cabinet dimensions
(W × H × D)
37 mm (W) × 107.5 mm (H) ×
15 mm (D)
Mass
Approx. 50 g with battery
Approx. 39 g without battery
Operating temperature 0 °C to 40 °C
Operating humidity
20% RH to 80% RH
(No condensation)
Internal memory 2 GB


Usable capacity will be less.
Approximate recordable time
(Depending on the conditions, it will become shorter.)
Sound quality Recording time
XP : MP3 192 kbps approx. 22 h.
LP : MP3 96 kbps approx. 44 h.
SLP : MP3 32 kbps approx. 132 h.
