● Alarm Setup [460]
The following procedures are only available when the AV Codec is set to TRANSMITTER in the [100 MODE] menu.
This menu lets you set the alarm methods when the codec located at the remote site receives an alarm signal from the associ-
ated alarm sensor.
The destinations called by the alarm dialing are specified with the quick (short) dial numbers previously registered. Before set-
ting this menu, be sure to register the quick (short) dial number in the [310 DIRECTORY REGI.] menu.
Transmitter
460 ALARM
461 ALARM SETUP
↓
462 ALARM DIALING TABLE1 ↓
463 ALARM DIALING TABLE2 ↓
464 ALARM DIALING TABLE3 ↓
↑↓ :MOVE ENT:SELECT ESC:PRV
460 ALARM
461 ALARM SETUP
↓
462 ALARM DIALING TABLE1 ↓
463 ALARM DIALING TABLE2 ↓
464 ALARM DIALING TABLE3 ↓
↑↓ :MOVE ENT:SELECT ESC:PRV
461 ALARM SETUP
ALARM TYPE: LEVEL EDGE
ALARM AUTO DISC TIMER : ..0S
ALARM DIALING TIME TABLE:
TABLE DAY TIME
1 MON-SUN 00:00-00:00
2 TUE-WED 09:00-00:00
3 THU-FRI 00:00-00:00
ENT:DAY INC. DEL:CLR
↑↓←→ :MOVE ESC:PRV
Move the cursor to the desired item by pressing the ▲ or ▼
button. Then press the ENTER button.
The selected item submenu appears on the monitor screen.
• 461 ALARM SETUP
Set the following items
•Alarm input methods
•Alarm dialing schedule
• 462 to 464 ALARM DIALING TABLE 1 to 3
Specifies the destination to be called when an alarm is
received from the associated alarm sensor.
● Alarm Setup [461]
1
Move the cursor to item 461 by pressing the
▲ or ▼ button. Then press the ENTER button.
The [461 ALARM SETUP] menu appears on the monitor
screen.
2
Move the cursor to the ALARM TYPE
parameter. Then select a mode by pressing
the Direction buttons.
This item lets you select the signal type for the alarm or
sensor input.
• LEVEL:
Accepts an alarm signal that remains on for a specific
time.
While the associated alarm sensor is on, the alarm
transmission will continue.
• EDGE:
Accepts an alarm signal that is a short pulse.
