● Serial Data Port Setup Verification [650]
● Local Loopback/Loopback Request [660]
● Loopback Test at Local Site (Local Loopback)
Communication speed (in bps)
Data length (in bits)
Stop bit (No. of bits)
Parity bit (No. of bits)
Remote site settings (displayed during communication only)
Local site settings
d
1
Select a line speed for the test by pressing
the t or s button.
2
Press the ENTER button to start the test.
The test menu now appears on the screen.
3
To end the test, press the ESC button.
• There will be no serial/parallel data loopback in a local
loopback test.
• If video is not input, a blue background is shown on the
screen during the test.
• View points cannot be changed using the numeric but-
tons during a loopback test.
• Loopback takes place through the line interface circuit
in the AV Codec.
Notes
Unless the local site settings are compatible with the
remote site settings, the serial data port cannot be
used.
If the displayed data differs, then check the settings of
both sites and modify them as required.
Note
