Move the cursor to the item in the menu by
pressing the ▲ or ▼ button. Then press the
ENTER button.
The selected item submenu appears on the monitor screen.
100: Sets an operation mode for the remote site.
Refer to the [100 MODE ] menu for further detail
setting.
200: Sets a receiving method for the remote site.
Refer to the [200 RECEIVING REGI.] menu for
further detail setting.
300: Edits the directory for the remote site.
Refer to the [300 DIRECTORY / DIALING REGI.]
menu for further setting detail.
400: Sets the system setup for remote site.
Refer to the [400 SETUP] menu for further setting
details.
6
After setting the desired items, press the ESC
button to return to the [700 REMOTE SETUP
EDIT] menu. Press the ESC button again.
The dialog menu appears, asking you to enable or disable
the uploading of the edited settings to the remote site.
7
Select [YES] by pressing the t or s button.
Then press the ENTER button.
The edited settings are uploaded to the remote site.
When the data is successfully uploaded, the line is auto-
matically disconnected and the AV Codec at the remote
site is restarted.
• Video, audio, and data cannot be sent during data
transfer.
• If the ESC button is pressed while the [NOW DOWN-
LOADING] display is on, a message appears, asking
whether or not to quit the data transfer. It can be quit by
first selecting [YES] with the Direction button and then
pressing the ENTER button.
• If an error occurs during data transfer, then a transfer
failure message appears. Press the ESC button to
return to the menu [000 TOP]. Repeat the above steps.
The settings edited are cleared when the codec
(Receiver) power is turned off.
Notes
