Note:
 • When"On"isselected,only"Unicastport(AUTO)"
will be available for "Transmission type".
 • When"On"isselected,itmaytakesecondstostart
displaying MPEG-4 images.
 • When"On"isselected,MPEG-4imagesmaynotbe
displayed depending on the number of the concur-
rent access users and audio data availability, etc.
 • When"On"isselected,onlyIPv4accessisavail-
able.
 • When"On"isselectedforeither"MPEG-4(1)"or
"MPEG-4(2)",themaximumconcurrentaccess
number is equal to or less than 10 users.
[Image capture size]
Select"QVGA"or"VGA"fortheimagecapturesizeof
MPEG-4 images.
Default: MPEG-4(1): VGA
MPEG-4(2): VGA
[Transmission priority]
Select "Constant bit rate" or "Frame rate" for the
MPEG-4 transmission mode.
Constant bit rate: MPEG-4 images will be transmitted
withthebitrateselectedfor"Maxbitrate(percli-
ent) *".
Frame rate: MPEG-4 images will be transmitted with
the frame rate selected for "Frame rate*".
Default: Constant bit rate
Note:
• When "Frame rate" is set for "Transmission priority",
number of users who can access the camera may
be limited more (may become less than 10).
[Frame rate*]
Select a frame rate for MPEG-4 images from the follow-
ing.
1fps/ 3fps/ 5fps*/ 7.5fps*/ 10fps*/ 12fps (PAL models)*/
15fps*/ 20fps*/ 30fps*
Default: 30fps*
Note:
 • When"Framerate"isselectedfor"Transmission
priority", this setting is available.
 • "Framerate*"issynchronizedwith"Maxbitrate
(per client)*". For this reason, the frame rate may be
lower than the specified value when any value
marked with an asterisk (*) is selected.
[Max bit rate (per client)*]
Select a MPEG-4 bit rate per a client from the following.
64kbps/ 128kbps*/ 256kbps*/ 384kbps*/ 512kbps*/
768kbps*/ 1024kbps*/ 1536kbps*/ 2048kbps*/
3072kbps*/ 4096kbps*/ Unlimited**
Default: MPEG-4(1): 2048kbps*
MPEG-4(2): 2048kbps*
* "Unlimited**" is available only when "Frame rate" is
selected for "Transmission priority".
Note:
 • TheMPEG-4bitrateissynchronizedwith
"Bandwidth control(bit rate)" on the [Network] tab of
"Network" page (☞ page 79). For this reason, the bit
rate may be lower than the value when any value
with an asterisk (*) on the right is selected.
 • When"Unlimited*" is selected, the number of users
who can access MPEG-4 images will be limited to
"1".(OnlyasingleusercanaccessMPEG-4
images.)
 • Itisimpossibletoselect"Unlimited*" for both
"MPEG-4(1)" and "MPEG-4(2)".
[Image quality]
Select the image quality of MPEG-4 images from the
following.
Fine(Image quality priority)/ Normal/ Low(Motion prior-
ity)
Default: Normal
Note:
 • When"Constantbitrate"isselectedfor
"Transmission priority", this setting is available.
[Refresh interval]
Select an interval (I-frame interval; 0.2 - 5 seconds) to
refresh the displayed MPEG-4 images.
If using under a network environment with frequent
error occurrences, shorten the refresh interval for
MPEG-4 to diminish image distortions. However, the
refresh interval may be longer than the set value.
0.2s/ 0.33s/ 0.5s/ 1s/ 2s/ 3s/ 4s/ 5s
Default: 3s
