Panasonic WV-SP300 Series

54
Step 1
Display the "Image adjust" setup menu. (☞ Page 49)
Step 2
Click the [Start] button of "Mask area".
→ Borders will appear and the image displayed on the
[Image/Privacy]tabwillbedividedinto48(6x8).
  Itwillbedividedinto32(4x8)when"16:9"is
selected for the aspect ratio.
Step 3
Click the divided areas to be masked.
→ The clicked areas will be masked and will become
white. To cancel masking, click the area again.
Step 4
Click the [End] button after completing masking areas.
→ The borders on the image displayed on the [Image/
Privacy] tab will disappear.
Important:
 • When"16:9"isselectedfortheaspectratioof
JPEG/H.264, the image will be displayed clipped
from the image of "4:3".
Therefore even when "16:9" is set, the brightness of
the nondisplayed masked area will affect the image,
it is recommended that the aspect ratio should be
once set to "4:3" before masking.
Image in the aspect ratio of "4:3"
Areas where the image is
not displayed when "16:9"
is selected for the aspect
ratio
Image in the aspect ratio of
"16:9" (Being cut out from
the aspect ratio of 4:3)
Note:
 • Whenthe[Reset]buttonisclicked,maskingforall
the masked areas will be canceled.
Set mask areas
When"Off"isselectedfor"Widedynamicrange(WDR)"(☞ page 50) and "Back light compensation(BLC)" (☞ page
51), it is possible to compensate for backlight by masking brighter areas.
