Magellan Wireless Expansion Module 21
ON, the activated PGM can only be deactivated by pressing the appropriate
button on the Magellan remote control (refer to section 7.2 on page 20).
8.0 Remote Control Programming
Depending on the system being used, the MG-RCV3 supports up to 16 fully
programmable remote controls without occupying any zones in the control panel.
For Spectra systems, up to 8 remote controls can be assigned to a MG-RCV3.
Digiplex series systems support up to 16 remote controls for every Magellan
module. The remote controls are programmed in three steps:
1. Assign remote controls to the MG-RCV3 (refer to section 8.1 on page 22).
2. Assign remote controls to Users (refer to section 8.2 on page 25).
3. Program the remote control buttons (refer to section 8.3 on page 26).
How to set the PGM deactivation mode:
Spectra
In step 3 in section 3.1 on page 8:
1. Enter section [610].
2. Enable or disable options [6] and [7].
Option [6] OFF = PGM 3: Deactivates after 2 seconds (default)
Option [6] ON = PGM 3: Manually (press RC button )
Option [7] OFF = PGM 4: Deactivates after 2 seconds (default)
Option [7] ON = PGM 4: Manually (press RC button )
Digiplex Series
In step 5 in section 3.2 on page 8:
1. Enter section [001].
2. Enable or disable options [6] and [7].
Option [6] OFF = PGM 3: Deactivates after 2 seconds (default)
Option [6] ON = PGM 3: Manually (press RC button )
Option [7] OFF = PGM 4: Deactivates after 2 seconds (default)
Option [7] ON = PGM 4: Manually (press RC button )
MGRCV3SD_EI01.fm Page 21 Thursday, May 5, 2005 2:22 PM
