26 Reference & Installation Manual
8.3 Program the Remote Control Buttons
SPECTRA: SECTIONS [711] TO [718]
D
IGIPLEX SERIES: SECTIONS [401] TO [416]
Each remote control can be programmed to send a signal to the control panel
to perform up to eight different actions (refer to Table 8.4 on page 30). Each
digit in the designated sections represents a button or button combination
(refer to Table 8.3 on page 28). When a user arms or disarms the system using
the remote control, the control panel will arm or disarm all the areas assigned
to the user code. For example, if you arm with a remote control whose user
code is assigned to areas 1 and 3, the control panel will attempt to arm areas 1
and 3.
Remote control buttons and (refer to Figure 8.2 on page 30)
automatically activate PGMs 3 and 4 respectively (refer to section 7.2
on page 20). If you program button or to perform another action,
pressing the button will activate the PGM and perform the
programmed action. For example, if button is programmed to
Regular arm the system, pressing button will activate PGM 3 and
Regular arm the system.
Digiplex Series
Sections [301] to [316] represent the remote controls assigned in sections
[201] to [216] respectively. For example, to assign the remote control that
was assigned in section [201] to a user, enter the appropriate user number
in section [301].
In step 5 in section 3.2 on page 8:
1. Enter a section number between [301] and [316].
2. Enter a user number.
DGP-848 = 001 to 096
DGP-NE96 = 001 to 255
MGRCV3SD_EI01.fm Page 26 Thursday, May 5, 2005 2:22 PM
