Magellan Wireless Expansion Module 31
* Since the MG-RCV3’s PGMs are always enabled and are activated only with Magellan remote
control buttons and respectively (refer to section 7.2 on page 20), the PGM and Utility Key
options pertain only to PGMs on other modules connected to the system. For Spectra systems,
refer to the PGM table (Event Group: 07, 08 and 09) in the Spectra Programming Guide. For DGP-
848 systems, refer to the PGM table (First Digit: 8) in the Digiplex 848 Programming Guide. For DGP-
NE96 systems, refer to the PGM table (Event Group: 048; Feature Group: 000; Start #001 to End
#005)) in the DGP-NE96 Programming Guide.
† The Panic feature must be enabled in the control panel.
In Digiplex versions prior to 2.12, button choices [1] to [9] will only
function with the System Master Code (Code 001).
8.3.1 Hexadecimal Values and Indicators
This section details how to enter hexadecimal values (1-F) using LCD
and LED keypads, and how the keypads display the hexadecimal
values.
[5] =Disarm [C] = Activates any PGMs that have Event
Group #08 as their Activation Event*
[6] = Disarm when there is
no alarm
[D] = Activates any PGMs that have Event
Group #09 as their Activation Event*
Digiplex Series
[0] = Button Disabled [8] = Panic 2† (Non-Medical)
[1] = Regular Arm [9] = Panic 3† (Fire)
[2] =Stay Arm [A] = Smoke reset
[3] = Instant Arm [B] = Utility Key 1*
[4]
=Force Arm
(not allowed in UL
listed systems)
[C] = Utility Key 2*
[5] =Disarm [D] = Utility Key 3*
[6] = Stay/Instant Disarm [E] = Utility Key 4*
[7] = Panic 1† (Police) [F] = Utility Key 5*
Table 8.4: Remote Control Button Options
MGRCV3SD_EI01.fm Page 31 Thursday, May 5, 2005 2:22 PM
