Magellan Wireless Expansion Module 23
Remote controls that are assigned to the MG-RCV3 do not occupy any
zones in the Spectra or Digiplex series control panel.
If a rejection beep is heard (“Beeeeeeeeeeeep”), or if you are having
trouble assigning the remote control, the environment may be too
noisy. Therefore, we recommend that you assign the remote controls
before installing the detectors and door contacts.
8.1.1 View the Assigned Remote Controls (Digiplex Series only)
DIGIPLEX SERIES: SECTIONS [040] AND [041]
Each remote control that is assigned to the MG-RCV3 is given a remote
control number (refer to Table 8.3 on page 28). The number of the
assigned remote controls are viewed in sections [040] and [041]. This
How to assign a remote control to a MG-RCV3:
Spectra (V1.23 or lower)
In step 3 in section 3.1 on page 8:
1. Enter a section number between [721] and [728].
2. Enter [111111]. A rejection beep will sound, and it will exit the section.
3. Press and hold any button on the remote control until you hear three
consecutive rejection beeps (“Beeeeeeeeeeeeeeep”). If no beeping is
heard, repeat the step until it does.
Spectra (V2.0 or higher)
In step 3 in section 3.1 on page 8:
1. Enter a section number between [731] and [738].
2. Press and hold any button on the remote control until the confirmation
beep sounds (“Beep-Beep-Beep-Beep-Beep”). If no beeping is heard,
repeat the step until it does.
Digiplex Series
In step 5 in section 3.2 on page 8:
1. Enter a section number between [201] and [216].
2. Press and hold any button on the remote control until the confirmation
beep sounds (“Beep-Beep-Beep-Beep-Beep”). If no beeping is heard,
repeat the step until it does.
MGRCV3SD_EI01.fm Page 23 Thursday, May 5, 2005 2:22 PM
