2 Reference & Installation Manual
Specifications may change without prior notice.
1.2 System Features
• Auto-Panel Recognition
• Add up to 16 wireless transmitters and up to 16 remote controls
• On-board anti-tamper switch
• Full system supervision (check-in, low battery and tamper)
• Transmitter signal strength indicator
• Transmitter battery life display (Digiplex series only)
2.0 Installation
The following sections will detail how to mount and connect the MG-RCV3.
2.1 Location
The locations of the MG-RCV3 and wireless transmitters affect the overall
performance of the wireless system. In order to ensure the best possible signal
reception, the following list of location criteria should be respected whenever
possible:
• Select an installation site that is free of obstacles that reflect and absorb
radio frequency (RF) signals, as well as interference that may distort signals.
Avoid installation near or in the path of strong RF fields (i.e. neon lights,
computers), and on or near metal objects, circuit breaker boxes, air
• Approvals: 433MHz
868MHz
• Range (typical in a
residential environment):
Refer to the appropriate transmitter
Instructions
Compliant to all EU and EFTA
countries except Greece according
to RTT&E directives.
868MHz version not approved by UL
MGRCV3SD_EI01.fm Page 2 Thursday, May 5, 2005 2:22 PM
