Magellan Wireless Expansion Module 5
1. The zone must be defined as a 24Hr Burglary zone
2. The zone’s alarm type must be set to Audible Alarm (pulsed)
3. The zone’s Auto-Zone Shutdown (zone option [1]) and Bypass
(zone option [2]) features must be disabled.
4. Change the zone’s report code from a burglary report code to a fire
report code. If using Ademco Contact I.D., set the Contact ID
Options from All Codes to Programmable (section [136] option [3] =
OFF) and then enter the report code manually.
Refer to the appropriate Spectra Reference & Installation
Manual and Programming Guide for more information on zone
programming.
Figure 2.1: Mounting
MGRCV3SD_EI01.fm Page 5 Thursday, May 5, 2005 2:22 PM
