PDL MICRODRIVE Series User Manual

Microdrive Series Instruction Manual
4201-109 Rev I
17
16x2 LCD DISPLAY
STATUS LEDs
"+" KEY
"-" KEY
"SELECT" KEY
SERIAL No. LABEL
MODEL NUMBER
INPUT & OUTPUT SPECIFICATION
PRODUCTION SERIAL NUMBER
SUPPLY SPECIFICATION
NOMINAL AC VOLTAGE RANGE
4807-019 Rev C
MANUFACTURED BY
PDL ELECTRONICS LTD
PO BOX 741, NAPIER
NEW ZEALAND
WARNING
STORED CHARGE
PRESENT SERVICING
DISCHARGE BEFORE
ALLOW 1 MINUTE TO
QUALIFIED PERSONNEL
SERVICE ONLY BY
MODEL
SERIAL No
VOLTAGE
FREQUENCY
CURRENT
: 48-62Hz
: 380-480 VAC -20 / +5% 3ph
Amps
XXX
XXXXX
XXX-XXX
:
:
:
Figure 1.1a The Microdrive-3 (UD3)
Figure 1.1b The Microdrive-i (UDi)
