149
Using the Flash
5
As shown in the illustration below, attach the Hot Shoe Adapter F
G
(optional) to the camera hot shoe and an Off-Camera Shoe Adapter F
(optional) to the bottom of the external flash, and connect these with the
Extension Cord F5P (optional). The Off-Camera Shoe Adapter F can be
mounted using the tripod screw to your tripod.
Only the P-TTL auto flash can be used in combination with the built-in flash.
When combining with the built-in flash
You can combine two or more external flashes (AF540FGZ, AF360FGZ or
AF200FG) or you can use two or more external flashes in combination with
the built-in flash. You can use the extension cord connection terminal on
the flash to connect the AF540FGZ. You can connect AF360FGZ or
AF200FG units as shown in the illustration below. Connect an external
flash and the Hot Shoe Adapter F (optional) to the Off-Camera Shoe
Adapter F (optional) and then connect another Off-Camera Shoe Adapter
F with external flash using the Extension Cord F5P (optional).
Refer to the flash manual for details.
Using the Built-in Flash with the External Flash
Discharging Multiple Flashes
• Do not combine with accessories that have a different number of contacts
such as a Hot Shoe Grip as a malfunction may occur.
• Combining with flashes from other manufacturers may cause equipment
breakdown. We recommend using the AF540FGZ, AF360FGZ or AF200FG.
