Pentax K20D User Manual

128
Shooting Functions
4
Using Mirror Up Function to Prevent
Camera Shake
Use the Mirror Up function if camera shake is evident even when cable
switch (optional) or remote control unit (optional) is used with a tripod.
When shooting with the 2 sec. Self-Timer, the mirror pops up and the
shutter is released 2 seconds after you press it, thereby avoiding the
vibration of the mirror.
Follow the procedure below to take a picture with the Mirror Up function.
1 Mount the camera onto a tripod.
2 In the Drive Mode, select Z (2 sec. Self-Timer).
1Self-Timer Shooting (p.122)
3 Press the shutter release button halfway.
The autofocus system operates. The focus indicator ] appears in the
viewfinder when focused.
4 Press the shutter release button fully.
The mirror pops up and the picture is taken 2 seconds later. AE lock is
enabled with the exposure value set immediately before the mirror goes
up.
The Shake Reduction function is automatically turned off when shooting with
the 2 sec. Self-Timer.

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
