Pentax K20D User Manual

175
Playback Functions
7
Displaying Multiple Images
You can display 4, 9 or 16 images on the monitor at the same time.
The default setting is 9-image display. The number of images can be
changed but 9-image display is explained here.
1 Press the Q button.
2 Turn the rear e-dial to the left
(toward f).
The multi-image display screen appears.
Up to nine thumbnail images will be
displayed at once. Use the four-way
controller (
2345 ) to select an image. A
scroll bar appears at the right of the screen.
With an image selected in the bottom row,
pressing the four-way controller (
3 )
displays the next nine images.
[?] appears for an image that cannot be
displayed.
100-0046
10 0 - 0 0 46
100-0046
1/2000
1/20 00
F5.6
F5.6
1/2000
F5.6
100-0046
Select&Delete
Scroll bar
Frame

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
