Before Using Your Camera
1
29
The following information appears in the LCD panel on top of the camera.
LCD Panel
1 Shutter speed (p.76) 6 Auto bracket (p.129)
2 Aperture (p.77)
(blinks when Exposure Bracket and
Extended Bracket are both set)
3 Flash mode (p.60)
b
: Built-in flash is ready 7 Flash exposure compensation (p.136)
(when blinking, flash should
be used)
8 EV compensation (p.100)
9 Battery level
>
: Red-eye reduction flash on 10 White balance (p.160)
(Not displayed when set to Auto)
3
: Auto discharge
Q : Slow-speed sync O : White balance correction
w : Wireless 11 Sensitivity display
Appears when sensitivity is displayed.
4 Drive mode (p.75)
9
: Single frame shooting 12 1 : RAW capture
j : Continuous shooting 1P : RAW+JPEG capture
g : Self-timer shooting 13 Recordable image no./
EV compensation/PC (Pb)
W
: Remote control shooting
5 EV bar (p.94, p.100) (PC: Personal Computer (mass
storage), Pb: PictBridge)
14 Multi-exposure (p.103)
Press the m button to illuminate the LCD panel. You can set it to not illuminate
in [27. Illuminate LCD panel] in the [A Custom Setting] menu.
2
1
3
5
9
7
8
12
11
6
13104
14

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
