Pentax K20D User Manual

75
Shooting Functions
4
Press the { button in Capture mode. The
Fn menu appears.
Press the four-way controller (2345)
or the 4 button to set the operation.
31. Display
Sensitivity
Sets whether to switch the number of recordable
images in the LCD panel and viewfinder to the
sensitivity display.
-
34. Catch-in focus
When set to [On], if the focus mode is set to l
and a manual focus lens is attached, catch-in
focus shooting is possible and the shutter is
released automatically when the subject comes
into focus.
p.112
35. AF Adjustment Performs AF adjustment. p.106
36. Using aperture
ring
Sets to enable shutter release when lens
aperture ring is set at other than s.
p.251
Reset Custom
Function
Resets all the settings in the Custom Setting
menu to the defaults.
p.239
Shooting Fn Menu Setting Items
Key or
Button
Item Function Page
2
Drive Mode
Selects Continuous shooting, Self-timer
or Remote control.
p.117,
p.122,
p.125
3
Flash Mode Adjusts the method of flash discharge. p.61
4
White Balance
Adjusts the color balance to match the
type of the light source illuminating the
subject.
p.160
5
Sensitivity Sets the sensitivity. p.78
4
Custom Image Sets image processing. p.154
Item Function Page
Exit
E x i t
Exit
Fn
AUTO
AUTO
AUTO
OK
Fn
CUSTOM IMAGE

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
