Pentax K20D User Manual

164
Shooting Settings
6
6 Press the shutter release button
fully.
Slide the focus mode lever to \ when
the shutter cannot be released.
The screen to select the measuring range
is displayed.
7 Use the rear e-dial to select the entire screen or spot area
for the measuring range.
8 When a spot area is selected, use the four-way controller
(2345) to move the frame to the area you want to
measure.
9 Press the 4 button.
The White Balance fine-tuning screen
appears when measuring is completed.
Tune using steps in “Fine-Tuning the
White Balance” if fine-tuning is
necessary. (p.162)
10 Press the 4 button.
The camera returns to the White Balance screen.
11 Press the 4 button.
The camera is ready to take a picture with the set White Balance.
• No image is recorded when the shutter release button is pressed to adjust
the white balance. Press the { button to save the background image as a
JPEG image. The image save confirmation screen appears. Select [Save as]
and press the 4 button.
• [NG] appears when measuring is unsuccessful. Press the 4 button while
displayed to return to the White Balance fine tune screen for remeasuring.
• If the picture is extremely overexposed or underexposed, white balance may
not be adjusted. In this case, adjust appropriate exposure and adjust the
white balance.
OK
O K
OK
OK
±0±0±0±0
±0±0
MENU
GG
BBA
A
A
MM
SHUTTER
OK
O K
OK
OK
Cancel
C a n c e l
Cancel
Manual
M a n u a l
White Balance
W h i t e B a l a n c e
Manual
White Balance

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
