45
Getting Started
2
Attaching a Lens
Attach a Q-mount lens to the camera’s body.
The steps will be described here using a 01 STANDARD PRIME lens.
1
Make sure that the camera is turned off.
2
Remove the body mount cover
(1) and lens mount cover (2).
Be sure to put the lens down with the lens
mount side facing upward to protect the
lens mount from damage.
3
Align the Lens mount index (red
dots: 3) on the camera and the
lens, and secure by turning the
lens clockwise until it clicks.
After attaching, turn the lens
counterclockwise to check that the lens is
locked in place.
• When attaching/removing the lens, choose an environment that is relatively
free of dirt and dust.
• Keep the body mount cover on the camera when a lens is not attached.
• Be sure to attach the lens mount cover and lens cap to the lens after
removing it.
• Do not insert any fingers into the camera mount or touch the CMOS sensor.
• The camera body and lens mount incorporate lens information contacts. Dirt,
dust, or corrosion may damage the electrical system. Please contact a
PENTAX Service Center for professional cleaning.
• We assume no responsibility nor liability for accidents, damages and
malfunctions resulting from the use of lenses made by other manufacturers.
3
