2014-02
100
IC-KP2-2HB17-2V1D
Appendix A
Response:
Send the command change tag to channel 2 as an implicit command:
Confirmation:
Response:
Byte no. Use Ty pe Description
Byte 0 Command code 04h Command CT (change tag)
Byte 1 Number of double words/
Channel/Toggle bit
02h Channel = 1
To gg le b it = 0
Byte 2 Statu s 00h Command executed.
Byte 3 Reply counter 02h For every ident telegram, the value
on the reply counter increases by
1.
Byte 4
...
Byte 11
00h
Byte no. Use Ty pe Description
Byte 0 Command code 04h Command CT (change tag)
Byte 1 Channel/Toggle bit 04h Channel = 2
To gg le b it = 0
Byte 2 Tag type (high byte) 30h IPC 02
Byte 3 Tag type (low byte) 32h IPC 02
Byte 4
...
Byte 11
00h
Byte no. Use Ty pe Description
Byte 0 Command code 04h Command CT (change tag)
Byte 1 Number of double words/
Channel/Toggle bit
04h Channel = 2
To gg le b it = 0
Byte 2 Statu s FFh Processing command.
Byte 3 Reply counter 03h For every ident telegram, the value
on the reply counter increases by
1.
Byte 4
...
Byte 11
00h
Byte no. Use Ty pe Description
Byte 0 Command code 04h Command CT (change tag)
Byte 1 Number of double words/
Channel/Toggle bit
04h Channel = 2
To gg le b it = 0
Byte 2 Statu s 00h Command executed.
Byte 3 Reply counter 04h For every ident telegram, the value
on the reply counter increases by
1.
Byte 4
...
Byte 11
00h
