Pepperl+Fuchs IC-KP2-2HB17-2V1D User Manual

IC-KP2-2HB17-2V1D
Appendix A
2014-02
101
Reading tags of the read/write heads on channel 1 and channel 2.
Send the command single read to channel 1 as an implicit command:
Confirmation
Response
Note!
Alternatively select the tag type by configuring the relevant setting in the boot-up object.
Byte no. Use Ty p e Description
Byte 0 Command code 01h Command SF (single read fixcode)
Byte 1 Channel/Toggle bit 02h Channel = 1
Toggle bit = 0
Byte 2 00h
Byte 3 00h
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
Byte 8 00h
Byte 9 00h
Byte 10 00h
byte 11 00h
Byte no. Use Ty p e Description
Byte 0 Command code 01h Command SF (single read fixcode)
Byte 1 Channel/Toggle bit 02h Channel = 1
Toggle bit = 0
Byte 2 Status FFh Processing command.
Byte 3 Reply counter 05h For every ident telegram, the value
on the reply counter increases by
1.
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
Byte 8 00h
Byte 9 00h
Byte 10 00h
byte 11 00h
Byte no. Use Ty p e Description
Byte 0 Command code 01h Command SF (single read fixcode)
Byte 1 Channel/Toggle bit 02h Channel = 1
Toggle bit = 0
Byte 2 Status 00h Command executed.
