Pepperl+Fuchs IC-KP2-2HB17-2V1D User Manual

2014-02
102
IC-KP2-2HB17-2V1D
Appendix A
Send the command single read to channel 2 as an implicit command:
Confirmation:
Byte 3 Reply counter 06h For every ident telegram, the value
on the reply counter increases by
1.
Byte 4 ID code 00h ... FFh - <ID code>
Byte 5 ID code 00h ... FFh - <ID code>
Byte 6 ID code 00h ... FFh - <ID code>
Byte 7 ID code 00h ... FFh - <ID code>
Byte 8 ID code 00h ... FFh -
<ID code>
1)
Byte 9 00h
Byte 10 00h
byte 11 00h
Table 11.1 1) only IPC02 and IPC11
Byte no. Use Ty pe Description
Byte 0 Command code 01h Command SF (single read fixcode)
Byte 1 Channel/Toggle bit 04h Channel = 2
To gg le b it = 0
Byte 2 00h
Byte 3 00h
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
Byte 8 00h
Byte 9 00h
Byte 10 00h
byte 11 00h
Byte no. Use Ty pe Description
Byte 0 Command code 01h Command SF (single read fixcode)
Byte 1 Channel/Toggle bit 04h Channel = 2
To gg le b it = 0
Byte 2 Statu s FFh Processing command.
Byte 3 Reply counter 07h For every ident telegram, the value
on the reply counter increases by
1.
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
Byte 8 00h
Byte 9 00h
Byte no. Use Ty pe Description
