Pepperl+Fuchs IC-KP2-2HB17-2V1D User Manual

IC-KP2-2HB17-2V1D
Appendix A
2014-02
103
Response:
Byte 10 00h
byte 11 00h
Byte no. Use Ty p e Description
Byte 0 Command code 01h Command SF (single read fixcode)
Byte 1 Channel/Toggle bit 04h Channel = 2
Toggle bit = 0
Byte 2 Status 00h Command executed.
Byte 3 Reply counter 08h For every ident telegram, the value
on the reply counter increases by
1.
Byte 4 ID code 00h ... FFh - <ID code>
Byte 5 ID code 00h ... FFh - <ID code>
Byte 6 ID code 00h ... FFh - <ID code>
Byte 7 ID code 00h ... FFh - <ID code>
Byte 8 ID code 00h ... FFh -
<ID code>
1)
Byte 9 00h
Byte 10 00h
byte 11 00h
Table 11.2 1) only IPC02 and IPC11
Byte no. Use Ty p e Description
