IC-KP2-2HB17-2V1D
Appendix A
2014-02
105
Setting tag type IPC03 on channels 1 and 2
Send the command change tag as an implicit command:
Confirmation:
Ele-
ment
Implicit
telegram
Use Type Description
1 Byte 0 Command code 04h Command CT (change tag)
Byte 1 Channel/Toggle bit 00h The element defines the
channel.
To gg l e b i t = 0
Byte 2 Ta g t y p e ( h i gh by te ) 30h IPC 03
Byte 3 Ta g t y p e ( lo w by te ) 33h IPC 03
Byte 4 00h Not used
Byte 5 00h Not used
Byte 6 00h Not used
Byte 7 00h Not used
2 Byte 8 Command code 04h Command CT (change tag)
Byte 9 Channel/Toggle bit 00h The element defined the
channel.
To gg l e b i t = 0
Byte 10 Ta g t y p e ( hi gh by te ) 30h IPC 03
byte 11 Ta g t y p e ( lo w by te ) 33h IPC 03
byte 12 00h Not used
Byte 13 00h Not used
Byte 14 00h Not used
Byte 15 00h Not used
3 Byte 16
...
Byte 23
00h Reserved
4 Byte 24
...
Byte 31
00h Reserved
Ele-
ment
Implicit
telegram
Use Type Description
1 Byte 0 Command code (Echo) 04h Command CT (change tag)
Byte 1 Channel/Toggle bit 02h Channel = element = 1
To gg l e b i t = 0
Byte 2 Status FFh Processing command.
Byte 3 Reply counter 01h For every ident telegram, the
value on the reply counter
increases by 1.
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
