Pepperl+Fuchs IC-KP2-2HB17-2V1D - Page 106

2014-02
106
IC-KP2-2HB17-2V1D
Appendix A
Response:
2 Byte 8 Command code (Echo) 04h Command CT (change tag)
Byte 9 Channel/Toggle bit 04h Channel = element = 2
Toggle bit = 0
Byte 10 Status FFh Processing command.
byte 11 Reply counter 01h For every ident telegram, the
value on the reply counter
increases by 1.
byte 12 00h Not used
Byte 13 00h Not used
Byte 14 00h Not used
Byte 15 00h Not used
3 Byte 16
...
Byte 23
00h Reserved
4 Byte 24
...
Byte 31
00h Reserved
Ele-
ment
Implicit
telegram
Use Ty p e Description
1 Byte 0 Command code 04h Command CT (change tag)
Byte 1 Number of double words/
Channel/Toggle bit
02h Channel = element = 1
Toggle bit = 0
Byte 2 Status 00h Command executed.
Byte 3 Reply counter 02h For every ident telegram, the
value on the reply counter
increases by 1.
Byte 4 00h
Byte 5 00h
Byte 6 00h
Byte 7 00h
2 Byte 8 Command code 04h Command CT (change tag)
Byte 9 Number of double words/
Channel/Toggle bit
04h Channel = element = 2
Toggle bit = 0
Byte 10 Status 00h Processing command.
byte 11 Reply counter 02h For every ident telegram, the
value on the reply counter
increases by 1.
byte 12 00h Not used
Byte 13 00h Not used
Byte 14 00h Not used
Byte 15 00h Not used
Ele-
ment
Implicit
telegram
Use Ty p e Description
