Pepperl+Fuchs IC-KP2-2HB17-2V1D User Manual

2014-02
116
IC-KP2-2HB17-2V1D
Appendix B
Output instance 111d - 248 bytes
Output instance 112d - 0 bytes
Input instance attributes (instances 150d-162d)
Input instance 150d - 8 bytes
Input instance 151d - 12 bytes
Input instance 152d - 32 bytes
Input instance 153d - 60 bytes
Input instance 154d - 32 bytes
Input instance 155d - 48 bytes
Bytes Class, instance, attribute Description
0 - 59 64h, 01d, 04h Channel 1 [60]
60 - 119 64h, 02d, 04h Channel 2 [60]
120 - 179 Reserved Reserved
180 - 239 Reserved Reserved
240 - 299 64h, 05d, 01h IDENTControl Compact
Bytes Class, instance, attribute Description
NONE N/A Heartbeat
Attribute ID Name Data type Data content Access
authorization
3 Input data USINT
[8-248]
0 Ge t
Bytes Class, instance, attribute Description
0 - 7 65h, 06d, 01h Mixed mode [8]
Bytes Class, instance, attribute Description
0 - 11 65h, 06d, 02h Mixed mode [12]
Bytes Class, instance, attribute Description
0 - 31 65h, 06d, 03h Mixed mode [32]
Bytes Class, instance, attribute Description
0 - 59 65h, 06d, 04h Mixed mode [60]
Bytes Class, instance, attribute Description
0 - 7 65h, 01d, 01h Channel 1 [8]
8 - 15 65h, 02d, 01h Channel 2 [8]
16 - 23 Reserved Reserved
24 - 31 Reserved Reserved
Bytes Class, instance, attribute Description
0 - 11 65h, 01d, 02h Channel 1 [12]
12 - 23 65h, 02d, 02h Channel 2 [12]
