IC-KP2-2HB17-2V1D
Appendix B
2014-02
117
Input instance 156d - 128 bytes
Input instance 157d - 240 bytes
Input instance 158d - 40 bytes
Input instance 159d - 56 bytes
Input instance 160d - 136 bytes
24 - 35 Reserved Reserved
36 - 47 Reserved Reserved
Bytes Class, instance, attribute Description
0 - 31 65h, 01d, 03h Channel 1 [32]
32 - 63 65h, 02d, 03h Channel 2 [32]
64 - 95 Reserved Reserved
96 - 127 Reserved Reserved
Bytes Class, instance, attribute Description
0 - 63 65h, 01d, 04h Channel 1 [60]
64 - 127 65h, 02d, 04h Channel 2 [60]
128 - 191 Reserved Reserved
192 - 255 Reserved Reserved
Bytes Class, instance, attribute Description
0 - 7 65h, 01d, 01h Channel 1 [8]
8 - 15 65h, 02d, 01h Channel 2 [8]
16 - 23 Reserved Reserved
24 - 31 Reserved Reserved
32 - 39 65h, 05d, 01h IDENTControl Compact
Bytes Class, instance, attribute Description
0 - 11 65h, 01d, 02h Channel 1 [12]
12 - 23 65h, 02d, 02h Channel 2 [12]
24 - 35 Reserved Reserved
36 - 47 Reserved Reserved
48 - 55 65h, 05d, 01h IDENTControl Compact
Bytes Class, instance, attribute Description
0 - 31 65h, 01d, 03h Channel 1 [32]
32 - 63 65h, 02d, 03h Channel 2 [32]
64 - 95 Reserved Reserved
96 - 127 Reserved Reserved
128 - 135 65h, 05d, 01h IDENTControl Compact
Bytes Class, instance, attribute Description
