IC-KP2-2HB17-2V1D
Commands
Single program special fixcode (SP)
Command:
Response:
The R/W head makes only one attempt to write a special read only code.
Byte Type Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (0Dh) 0 0 0 0 1 1 0 1
Byte 3 Word number/Ident channel/Toggle bit <FixLen> <Channel> <T>
Byte 4 Reserved 0 0 0 0 0 0 0 0
Byte 5 Reserved 0 0 0 0 0 0 0 0
Byte 6 ID code 00h ... FFh <ID code>
Byte 7 ID code 00h ... FFh <ID code>
Byte 8 ID code 00h ... FFh <ID code>
Byte 9 ID code 00h ... FFh <ID code>
Byte 10 ID code 00h ... FFh <ID code>
byte 11 ID code 00h ... FFh <ID code>
Byte Type Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (0Dh) 0 0 0 0 1 1 0 1
Byte 3 FixLen/Ident channel/Toggle bit <FixLen> <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
Byte 6 not used - - - - - - - -
Byte 7 not used - - - - - - - -
Byte 8 not used - - - - - - - -
Byte 9 not used - - - - - - - -
Table 7.30 * this byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Note!
The <FixLen> of IDC-...-1K read/write tags is always 6 bytes.
