Enhanced program special fixcode (EP)
Command:
Response:
The R/W head attempts to write a special read only code until successful. After each
successful write, the head sends the response and then switches to continuous reading. Then
the R/W head reads the same data carrier until it has left the detection range or a new data
carrier appears within the detection range. The command then starts again with write attempts.
The status '05h' (read/write command) is output when the data carrier leaves the detection
range or if the data carrier is not yet within the detection range when the command is executed.
If two data carriers enter the read range one immediately after the other, the status '05h' is not
issued between the two readings.
Byte Ty pe Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (75h) 0 1 1 1 0 1 0 1
Byte 3 FixLen/Ident channel/Toggle bit <FixLen> <Channel> <T>
Byte 4 Reserved 0 0 0 0 0 0 0 0
Byte 5 Reserved 0 0 0 0 0 0 0 0
Byte 6 ID code 00h ... FFh <ID code>
Byte 7 ID code 00h ... FFh <ID code>
Byte 8 ID code 00h ... FFh <ID code>
Byte 9 ID code 00h ... FFh <ID code>
Byte 10 ID code 00h ... FFh <ID code>
byte 11 ID code 00h ... FFh <ID code>
Byte Ty pe Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (75h) 0 1 1 1 0 1 0 1
Byte 3 FixLen/Ident channel/Toggle bit <FixLen> <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
Byte 6 not used - - - - - - - -
Byte 7 not used - - - - - - - -
Byte 8 not used - - - - - - - -
Byte 9 not used - - - - - - - -
Table 7.31 * this byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
Note!
The <FixLen> of IDC-...-1K read/write tags is always 6 bytes.
