IC-KP2-2HB17-2V1D
Commands
Initialize tag (SI)
Command:
Response:
This command allows conventional reading and writing of IDC-...-1K read/write tags that were
configured using the EP or SP commands.
Byte Type Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 0 1 0 0
Byte 2 Command code (6Bh) 0 1 1 0 1 0 1 1
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte Type Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 1 0 1 1
Byte 2 Command code (6Bh) 0 1 1 0 1 0 1 1
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
Byte 6 not used - - - - - - - -
Byte 7 not used - - - - - - - -
Byte 8 not used - - - - - - - -
Byte 9 not used - - - - - - - -
Byte 10 not used - - - - - - - -
Table 7.32 * this byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
