70 . Lambda XLS/XLS+ User's Guide
18. Repeat Step 17 for each sample.
Press
to display the available method options, which you can select using the
keypad numbers:
1 Method Settings Returns to the Method Settings screen.
2 Print Prints using the printer selected in the Utilities folder.
3 Show Graph Toggles the graph on and off. The graph shows a spectrum across
the range of the measured wavelengths, which are marked by
cursors.
7 Sample Number Adds a prefix to the sample number and resets the incrementing
number to the desired value.
8 Save Method Use the left and right arrows to select the folder you want to store
the method in (Favorites/Methods 1–9/SD Memory Card), then
press the down arrow and enter a name for the method. Press
Save
to save the method.
9 Auto-Print Toggles Auto-Print on and off.
Press or , or wait 20 seconds to exit the method options.
Press
to return to the Standard Methods folder after all your samples have been
measured.
