20 KENR6933
Troubleshooting Section
Table 5
Connector
Function
P1
Machine Harness to ECM Connector (64 Pin Connector)
P2
Engine Harness to ECM Connector (64 Pin Connector)
P532
Fuel Rail Pump Solenoid Connector (2 Pin Connector)
P402
Secondary Speed/Timing Sensor (2 Pin Connector)
P401
Primary Speed/Timing Sensor (2 Pin Connector)
P201
Engine Oil Pressure Sensor (3 Pin Connector)
P228
Fuel Rail Pressure Sensor (3 Pin Connector)
P200 Intake Manifold Pressure Sensor (3 Pin Connector)
P103 Intake Manifold Temperature Sensor (2 Pin Connector)
P100 Coolant Temperature Sensor (2 Pin Connector)
J23
Diagnostic C
onnector (if equipped)
P691/J691 Electronic Unit Injectors for No. 1 and No. 2 Cylinders (4 Pin
Connector)
P692/J692 Electronic Unit Injectors for No. 3 and No. 4 Cylinders (4 Pin
Connector)
P693/J693 Electronic Unit Injectors for No. 5 and No. 6 Cylinders (4 Pin
Connector)
P511
Wastegate regulator (if equipped) (2 Pin Connector)
