72 KENR6933
Troubleshooting Section
(Table 34, cont
d)
CDL Code Description
3rd Party
Device
J1939
Code
Flash
Code
E360-3
Low Oil Pressure - Shutdown
100-01 157
E361-1
High Engine Coolant Temperature - Warning
110-15 168
E361-2
High Engine Coolant Temperature - Derate
110-16 168
E361-3
High Engine Coolant Temperature - Shutdown
110-00 168
E362-1 Engine Overspeed 190-15 141
E396-1 High Fuel Rail Pressure 157-00 159
E398-1 Low Fuel Rail Pressure 157-01 159
E539-1
High Intake Manifold Air Temperature - W arning
105-15 133
E539-2
High Intake Manifold Air Temperature - Derate
105-16 133
E2143-3
Low Engine Coolant Level
111-01 169
i02412499
No Diagnosti
c Co des Detected
Conditions Which G enerate This Code:
A flash code 05
51 indicates that there are no detected
faults in the system since the previous powering up.
System Respo
nse:
This code will not appear on the electronic service
tool. The in
dicator lamps will flash the diagnostic
code. For more information on flash codes, refer to
Troubleshooting, “Indicator Lamps”.
Possible Performance E ffect:
None
There are no faults that require troubleshooting.
Results:
•
OK – STOP.
i02655551
CID 0001 FMI
02
Conditions Which G enerate This Code:
The Electro
nic Control Module (ECM) detects the
following condition:
•
Data from the electronic unit injector for the No. 1
cylinder is out of limits.
•
Diagnostic code 0168-01 is not active.
•
Diagnostic codes 0001-05 and 0001-06 are not
active.
•
No 0041 diagnostic codes are active.
•
No 0262 diagnostic codes are active.
•
Diagnostic code 0190-08 is not active.
•
No 0110 diagnostic codes are active.
System Response:
If equipped, the warning light will come on. An active
diagnostic code will be generated. The ECM will log
the diagnostic code.
Possible Performance Effect:
The engine will be derated while this diagnostic code
is active.
Troubleshooting:
Perform the following diagnostic procedure: “Injector
Data Incorrect - Test”
Results:
•
OK – STOP.
