Perkins 1106C - Page 71

KENR6933 71
Troubleshooting Section
(Table 34, cont
d)
CDL Code Description
3rd Party
Device
J1939
Code
Flash
Code
0091-04 Accelerator pedal - voltage below normal 91-04 154
0091-08 Throttle Position signal abnormal 91-08 154
0100-03 Engine Oil Pressure open/short to +batt 100-03 157
0100-04 Engine Oil Pressure short to ground 100-04 157
0100-10 Engine Oil Pressure Sensor abnormal rate of change 100-10 157
0110-03
Engine Coolan
t Temperature open/short to +batt 110-03 168
0110-04
Engine Coolant Temperature short to ground
110-04 168
0168-00
System Voltage H igh
168-00 422
0168-01
System Voltage Low
168-01 422
0168-02
System Voltage intermittent/erratic
168-02 422
0172-03 Intake Manifold Air Temp open/short to +batt 105-03 133
0172-04 Intake Manifold Air Temp short to ground 105-04 133
0190-08 Engine Speed signal abnormal 190-08 141
0247-09 J1939 Data Link communications
-
514
0247-12
J1939 Data Li
nk malfunction
-
514
0253-02 Personality Module mismatch 631-02 415
0261-11 Engine Timing Offset fault 637-11 143
0262-03 5 Volt Sensor DC Power Supply short to +batt 1079-03 516
0262-04 5 Volt Sensor DC Power Supply short to ground 1079-04 516
0268-02 Check Programmable Parameters 630-02 527
0342-08 Secondary Engine Speed signal abnormal 723-08 142
0526-05 Turbo Wastegate Drive current low 1188-05 177
0526-06 Turbo Wastegate Drive current high 1188-06 177
0526-07 Turbo Wastegate Drive not responding properly 1188-07 177
1779-05 Fuel Rail Pressure Valve 1 Solenoid open circuit 1347-05 162
1779-06 Fuel Rail Pressure Valve 1 Solenoid short to ground 1347-06 162
1785-03
Intake Man
ifold Pressure Sensor voltage high 102-03 197
1785-04
Intake Manifold Pressure Sensor voltage low
102-04 197
1785-10
Intake Manifold Pressure Signal abnormal rate of change
102-10 197
1797-03
Fuel Rail Pressure Sensor open/short to +batt
157-03 159
1797-04
Fuel Rail Pressure Sensor short to ground
157-04 159
1834-02 Ignition Keyswitch loss of signal 158-02 439
2246-06 Glow plug Start Aid Relay Current High 676-06 199
Event Codes
E172-1 High Air Filter Restriction 107-15 151
E232-1
High Fuel
/Water Separator Water Level 97-15
-
E360-1
Low Oil Pressure - Warning
100-17 157
(continued)
