Perkins 1106C - Troubleshooting With Diagnostic Codes

70 KENR6933
Troubleshooting Section
Troubleshooti
ng with a
Diagnostic Code
i02444929
Diagnostic Code Cross
Reference
Table 34
CDL Code Description
3rd Party
Device
J1939
Code
Flash
Code
N/A No Diagnostic Code Detected N/A 551
0001-02 Cylinder #1 Injector Data Incorrect 651-2 111
0001-05 Cylinder #1 Injector open circuit 651-5 111
0001-06 Cylinder #1 Injector short 651-6 111
0001-07 Cylinder #1 Injector Not Responding 651-7 111
0002-02
Cylinder #2
Injector D ata Incorrect 652-2 112
0002-05
Cylinder #2 Injector open circuit
652-5 112
0002-06
Cylinder #2 Injector short
652-6 112
0002-07
Cylinder #2 Injector Not Responding
652-27 112
0003-02
Cylinder #3 Injector Data Incorrect
653-2 113
0003-05 Cylinder #3 Injector open circuit 653-5 113
0003-06 Cylinder #3 Injector short 653-6 113
0003-07 Cylinder #3 Injector Not Responding 653-7 113
0004-02 Cylinder #4 Injector Data Incorrect 654-2 114
0004-05 Cylinder #4 Injector open circuit 654-5 114
0004-06 Cylinder #4 Injector short 654-6 114
0004-07 Cylinder #4 Injector Not Responding 654-7 114
0005-02
Cylinder
#5 Injector D ata Incorrect 655-2 115
0005-05
Cylinder #5 Injector open circuit
655-5 115
0005-06
Cylinder #5 Injector short
655-6 115
0005-07
Cylinder #5 Injector Not Responding
655-7 115
0006-02
Cylinder #6 Injector Data Incorrect
656-2 116
0006-05 Cylinder #6 Injector open circuit 656-5 116
0006-06 Cylinder #6 Injector short 656-6 116
0006-07 Cylinder #6 Injector Not Responding 656-7 116
0041-03 8 Volt DC Supply short to +batt 678-03 517
0041-04 8 Volt DC Supply short to ground 678-04 517
0091-03 Accelerator pedal - voltage above normal 91-03 154
(continued)
