(Table 8, contd)
1235-9
J1939 Network #3 : Abnormal Up-
date Rate
5856-9
SAE J1939 Data Link #3 : Abnormal Up-
date Rate
Troubleshooting, “CAN Data Link - Test”
1235-14
J1939 Network #3 : Special
Instruction
5856-14
SAE J1939 Data Link #3 : Special
Instruction
Troubleshooting, “Data Link Configuration Status - Test”
1761-2
Aftertreatment #1 DEF Tank Volume
: Erratic, Intermittent, or Incorrect
3130-2
Aftertreatment #1 DEF Tank #1 Level
Sensor : Erratic, Intermittent, or
Incorrect
Troubleshooting, “DEF Tank Sensor - Test”
1761-12
Aftertreatment #1 DEF Tank Volume
: Failure
3130-12
Aftertreatment #1 DEF Tank #1 Level
Sensor : Failure
Troubleshooting, “DEF Tank Sensor - Test”
2791-5
Engine Exhaust Gas Recirculation
(EGR) Valve Control : Current Below
Normal
3405-5
EGR Valve Control : Current Below
Normal
Troubleshooting, “Motorized Valve - Test”
2791-6
Engine Exhaust Gas Recirculation
(EGR) Valve Control : Current Above
Normal
3405-6
EGR Valve Control : Current Above
Normal
Troubleshooting, “Motorized Valve - Test”
2882-2
Engine Alternate Rating Select : Er-
ratic, Intermittent, or Incorrect
1743-2
Engine Operation Mode Selector Switch
: Erratic, Intermittent, or Incorrect
Troubleshooting, “Mode Selection - Test”
2970-2
Accelerator Pedal #2 Low Idle Switch
: Erratic, Intermittent, or Incorrect
1635-2
Idle Validation Switch #2 : Erratic, Inter-
mittent, or Incorrect
Troubleshooting, “Idle Validation - Test”
3031-12
Aftertreatment #1 DEF Tank Temper-
ature : Failure
3134-12
Aftertreatment #1 DEF Tank #1 Temper-
ature Sensor : Failure
Troubleshooting, “DEF Tank Sensor - Test”
3216-5
Aftertreatment #1 Intake NOx : Cur-
rent Below Normal
3002-5
Engine Exhaust NOx Level Sensor :
Current Below Normal
Troubleshooting, “Electrical Power Supply - Test”
3216-6
Aftertreatment #1 Intake NOx : Cur-
rent Above Normal
3002-6
Engine Exhaust NOx Level Sensor :
Current Above Normal
Troubleshooting, “Electrical Power Supply - Test”
3216-11
Aftertreatment #1 Intake NOx : Other
Failure Mode
3002-11
Engine Exhaust NOx Level Sensor :
Other Failure Mode
Troubleshooting, “Sensor (Data Link Type) - Test”
3216-12
Aftertreatment #1 Intake NOx :
Failure
3002-12
Engine Exhaust NOx Level Sensor :
Failure
Troubleshooting, “Sensor (Data Link Type) - Test”
3226-5
Aftertreatment #1 Outlet NOx : Cur-
rent Below Normal
3609-5
Aftertreatment #1 Outlet #1 NOx Level
Sensor : Current Below Normal
Troubleshooting, “Electrical Power Supply - Test”
3226-6
Aftertreatment #1 Outlet NOx : Cur-
rent Above Normal
3609-6
Aftertreatment #1 Outlet #1 NOx Level
Sensor : Current Above Normal
Troubleshooting, “Electrical Power Supply - Test”
3226-11
Aftertreatment #1 Outlet NOx : Other
Failure Mode
3609-11
Aftertreatment #1 Outlet #1 NOx Level
Sensor : Other Failure Mode
Troubleshooting, “Sensor (Data Link Type) - Test”
(continued)
UENR4469-36 37
Diagnostic Trouble Codes
