(Table 10, contd)
Event Codes
J1939 Code and Description PDL Code and Description
Troubleshooting Procedure
4360-16
Aftertreatment #1 SCR Catalyst In-
take Gas Temperature : High - mod-
erate severity (2)
E946 (2)
High Aftertreatment #1 SCR Catalyst
Intake Gas Temperature
Troubleshooting, “SCR Catalyst Has Incorrect Inlet
Temperature”
4360-17
Aftertreatment #1 SCR Catalyst In-
take Gas Temperature : Low - least
severe (1)
E947 (1)
Low Aftertreatment #1 SCR Catalyst In-
take Gas Temperature
Troubleshooting, “SCR Catalyst Has Incorrect Inlet
Temperature”
4360-18
Aftertreatment #1 SCR Catalyst In-
take Gas Temperature : Low - mod-
erate severity (2)
E947 (2)
Low Aftertreatment #1 SCR Catalyst In-
take Gas Temperature
Troubleshooting, “SCR Catalyst Has Incorrect Inlet
Temperature”
4364-2
Aftertreatment #1 SCR Catalyst
Conversion Efficiency : Erratic, In-
termittent, or Incorrect
E1410 (2)
Invalid Aftertreatment #1 SCR Conver-
sion Efficiency
Troubleshooting, “NOx Sensor - Test”
4364-18
Aftertreatment #1 SCR Catalyst
Conversion Efficiency : Low - mod-
erate severity (2)
E1309 (2)
Low Aftertreatment #1 SCR Catalyst
Conversion Efficiency
Troubleshooting, “NOx Conversion Is Low”
4765-17
Aftertreatment #1 Diesel Oxidation
Catalyst Intake Gas Temperature :
Low - least severe (1)
E2165 (1)
Low Aftertreatment #1 Diesel Oxidation
Catalyst #1 Intake Gas Temperature
Troubleshooting, “Diesel Oxidation Catalyst Has Incorrect Inlet
Temperature”
5246-0
Aftertreatment SCR Operator In-
ducement Severity : High - most se-
vere (3)
E1389 (3)
Aftertreatment #1 SCR Operator
Inducement
Troubleshooting, “SCR Warning System Problem”
5246-15
Aftertreatment SCR Operator In-
ducement Severity : High - least se-
vere (1)
E1389 (1)
Aftertreatment #1 SCR Operator
Inducement
Troubleshooting, “SCR Warning System Problem”
5246-16
Aftertreatment SCR Operator In-
ducement Severity : High - moder-
ate severity (2)
E1389 (2)
Aftertreatment #1 SCR Operator
Inducement
Troubleshooting, “SCR Warning System Problem”
5298–17
Aftertreatment 1 Diesel Oxidation
Catalyst Conversion Efficiency :
Low - least severe (1)
E2180 (1)
Low Aftertreatment #1 Diesel Oxidation
Catalyst #1 Conversion Efficiency
Troubleshooting, “Diesel Oxidation Catalyst Has Low Conver-
sion Efficiency”
5392-31
Aftertreatment Diesel Exhaust Fluid
Dosing Unit Loss of Prime
E1370 (2)
Aftertreatment #1 DEF Dosing Unit
Loss of Prime
Troubleshooting, “DEF Pressure Does Not Respond”
5571-0
High Pressure Common Rail Fuel
Pressure Relief Valve : High - most
severe (3)
E1264 (2)
High Pressure Common Rail Fuel Pres-
sure Relief Valve Active
Troubleshooting, “Fuel Rail Pressure Problem”
5588-14
Proprietary Network #2 : Special
Instruction
E1132 (2)
Inconsistent Configuration Detected
Troubleshooting, “Data Link Configuration Status - Test”
(continued)
UENR4469-36
57
Event Codes
